Reference
Code
Description/Action
(Perform all actions before exchanging Failing
Items)
Failing Item
110D Regulator R06 error
A fault detection failure occurred for regulator
R06.
1. Programmable regulator assembly R06
Location: U1.1-P2-V6
2. SPCN card
Location: U1.1-P2-X1
110E Regulator R07 error
A fault detection failure occurred for regulator
R07.
1. Programmable regulator assembly R07
Location: U1.1-P2-V7
2. SPCN card
Location: U1.1-P2-X1
110F Regulator R08 error
A fault has been detected for a non-existent
regulator.
1. SPCN card
Location: U1.1-P2-X1
1110 Regulator R09 error
A fault detection failure occurred for regulator
R09.
1. Programmable regulator assembly R09
Location: U1.1-P2-V9
2. SPCN card
Location: U1.1-P2-X1
1111 Regulator R10 error
A fault detection failure occurred for regulator
R10.
1. Programmable regulator assembly R10
Location: U1.1-P2-V10
2. SPCN card
Location: U1.1-P2-X1
111C Regulator R21 error
A fault detection failure occurred for regulator
R21.
1. Processor regulator card R21, Slot M04
Location: U1.1-P1-V1
2. SPCN card
Location: U1.1-P2-X1
111D Regulator R22 error
A fault detection failure occurred for regulator
R22.
1. Processor regulator card R22, Slot M07
Location: U1.1-P1-V2
2. SPCN card
Location: U1.1-P2-X1
111E Regulator R23 error
A fault detection failure occurred for regulator
R23. This regulator is included in clock/processor
regulator card in slot M19.
1. Clock/processor regulator card R23, Slot M19
Location: U1.1-P1-X2
2. SPCN card
Location: U1.1-P2-X1
1200 29V bus fault
A 29V bus fault has been detected.
Go to “MAP 1520: Power” on page 88.
1201 2.5V processor regulator fault
A 2.5V regulator fault has been detected.
Go to “MAP 1520: Power” on page 88.
1202 3.3V processor regulator fault
A 3.3V regulator fault has been detected.
Go to “MAP 1520: Power” on page 88.
1xxx
Chapter 5. Error Code to FRU Index 193
