IBM System x3550 M3 Type 4254 Problem Determination And Service Guide

Table 10. Parts listing, Types 4254 and 7944 (continued)
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU part
number
17 Hard disk drive, 2.5-inch hot-swap, 500 GB, 10 K 42D0708
17 Hard disk drive, 2.5-inch hot-swap, 600 GB, 10 K 49Y2004
18 Backplate assembly, simple-swap 59Y3919
19 Backplane, SAS 59Y3915
20 Fan 43V6929
21 System board 69Y4508
22 ServeRAID-M1015 adapter (models B2x, C2x, D2x, H2x,
and N2x)
46M0861
23 ServeRAID-BR10il v2 adapter (model A2x) 49Y4737
24 SAS/SATA riser card 43V7067
25 Retention module, heat sink 49Y4822
26 Microprocessor, 1.86 GHz 40W 69Y0783
26 Microprocessor, 2.13 GHz 40W (model C2x) 59Y3691
26 Microprocessor, 2.13 GHz 80W (model A2x) 46D1270
26 Microprocessor, 2.26 GHz 80W (model B2x) 69Y0782
26 Microprocessor, 2.26 GHz 60W (model H2x) 49Y7054
26 Microprocessor, 2.40 GHz 80W (model D2x) 49Y7053
26 Microprocessor, 2.53 GHz 80W (model F2x) 49Y7052
26 Microprocessor, 2.66 GHz 80W (model G2x) 49Y7051
26 Microprocessor, 2.66 GHz 95W (model J2x) 49Y7040
26 Microprocessor, 2.93 GHz 95W (model M2x) 49Y7038
26 Microprocessor, 3.33 GHz 130W (model N2x) 69Y0849
27 Heat sink assembly (models A2x, B2x, C2x, D2x, F2x, G2x,
H2x, J2x, and M2x)
49Y4820
27 Heat sink assembly, 130W (model N2x) 69Y1207
28 Air baffle kit (Microprocessor air baffle, clamp, and DIMM
air duct) (all models)
59Y3914
Cable, hard disk drive configuration 59Y3918
Cable, operator panel 46C4139
Cable, SAS power 59Y3920
Cable, SAS signal, 300 mm 49Y4850
Cable, SAS signal, 450 mm 59Y3921
Cable, SAS signal, 710 mm 69Y1328
Cable, SATA DVD 59Y3922
Cable, USB/video 59Y3923
Cable, line cord (models A2x, B2x, C2x, D2x, F2x, G2x,
H2x, J2x, M2x, and N2x)
39M5377
Cage, hard disk drive 59Y3968
Cage, optical drive 59Y3924
Safety cover 49Y4823
162 IBM System x3550 M3 Types 4254 and 7944: Problem Determination and Service Guide

IBM System x3550 M3 Type 4254 Specifications

General

Processor	Intel Xeon 5600 series
Max Processors	2
Memory	Up to 192 GB DDR3
Form Factor	1U Rack
Chipset	Intel 5520
Drive Bays	Up to 4 hot-swap 2.5-inch SAS/SATA or SSD
RAID Support	RAID 0, 1, 10
Network Interface	Dual-port Gigabit Ethernet
Power Supply	460W or 675W
Expansion Slots	2 PCIe 2.0
Weight	Approximately 17.24 kg (38 lbs)
Memory Slots	18 (RDIMM) or 12 (UDIMM)
