E3001 ‘Perform Motor Calibration’ - Motors have not been
calibrated. Calibrate via CLARiTY Config
Fault
E3002 ‘Printhead Resistance Not Set’ - Set the printhead
resistance on CLARiTY - Tools>Setup>Print-
head>Printhead resistance
Fault
E3003 ‘Cassette Open’ - Re-insert the ribbon cassette into
the printer
Fault
E3004 ‘Ribbon Break’ - Print ribbon has broken or run out Fault
E3005 ‘End of Reel’ - Print ribbon has run out Fault
E3006 ‘Calibration Failed’ - Ensure that the correct ribbon is
being used and the ribbon core is not slipping on man-
drel bodies.
Fault
E3007 ‘Printhead Crash’ - Printhead carriage is jammed.
Remove the cassette and check for any obstruction
Fault
E3008 ‘Optical Calibration Dirty’ - Remove the cassette and
clean the optical sensors on the printhead carriage
and the printer body.
Fault
E3009 ‘Bad Optical Calibration’ - Ribbon cores are of incor-
rect size
Fault
E3010 ‘Thermistor Fault’ - Printer has detected fault with the
thermistor or the thermistor is disconnected.
Fault
E3011 ‘Printhead Over Temperature’ - Coder operating over
65 degrees Celsius
Fault
E3012 ‘Low Ribbon’ - Less than 50 metres of ribbon left on
the reel
Warning
E3013 ‘Printhead Absent’ - Communications between
CLARiTY and the printer have been lost, check the
cabling.
Fault
E3014 ‘Webbing Error’ - The ribbon has been incorrectly
loaded onto the cassette.
Fault
E3015 ‘Motor Volts Error’ Fault
E3016 ‘Printhead Volts Error’ Fault
E3017 ‘Check the Set Up’ - Substrate speed and the encoder
speed do not match. Ribbon speed is not matched to
substrate speed.
Fault
E3018 ‘Ribbon Pull Through’ - Ribbon is 'stuck' to the sub-
strate and has been pulled from the cassette.
Fault
Error
No
Report on CLARiTY Operator Interface Status
Table 6-1: List of Faults and Warnings
