Rev AA Mounting Considerations 3-7
Air Regulator
The air regulator should be connected to a clean, dry factory air supply
using a 6 mm pipe. The 4 mm diameter pipe should be used to connect the
air regulator to the printer.
The air regulator should be mounted close to the printer. The regulator
should be accessible for adjusting and checking the correct pressure of 3
bar.
Encoders
An encoder is used to match the printing speed to the speed of the target
material as it passes the printhead.
Use the Encoder Kit part number 403358 for these applications.
The encoder must ideally be mounted to run on the packaging film, close
to the printer, in order to accurately measure the film speed. Any
discrepancy between measured and actual film speed can result in poor
print quality or ribbon breakage.
Note: Use the encoder only in the continuous mode.
ICE Pegasus Service Manual
