5-2

Maintaining the Power Supply

Rev AA

Maintaining the Power Supply

This section contains the information on how to replace the fuse.

Replacing the Mains Fuse

The fuses are the only user-serviceable parts in the power supply unit.

To replace the mains fuse, proceed as follows:

1 Using a small screwdriver, press and turn the fuseholder

anticlockwise, and remove the fuseholder (Figure 5-1).

2 Replace the five ampere fuse if it is defective (Figure 5-2).

Fuseholder

Figure 5-1: Fuseholder

Fuse

Figure 5-2: Fuse

E Pegasus Service Manual
