Maintaining the CLARiTY Controller
Replacing the Power Supply Unit
To open and replace the Power Supply Unit, proceed as follows:
1 Remove the top cover from the base of the CLARiTY Unit by
unscrewing the 5 screws shown in Figure 5-3.
Figure 5-3: Controller Opening
1. Screws (x5)
2. Top Cover
