Rev AA Working with the Inputs and Outputs 3-25
Loading a Saved Archive
To load an archive that was saved previously, proceed as follows:
1 Locate the archive in the left panel and right click on it.
2 Choose Load from the pop-up menu.
The archived parameters are displayed on the right-hand pane.
Click the printer icon from the left-hand panel and click the Download
button to load the archive of parameters to the printer.
Working with the Inputs and Outputs
The printer has a number of input/outputs for interfacing the printer to
the packaging equipment or the packaging line.
The Inputs
The inputs are pre-configured as:
• Print Sensor: Using a 24 V PNP input to trigger the printer
to start
printing
•
Inhibit Print: Using a 24 V PNP input to inform the printer that the
host packaging machine or line has
an error and the printer
should
not print.
•
Spare Input 1: Not Available for Use
Repeat the steps 1 to 5 for all the three inputs and then download the
parameters to the printer to apply these new settings.
The Outputs
The Outputs are pre-configured as follows:
• Output 1: Printer enters fault: A fault condition has occurred
• Output 2: Printer enters warning: A warning condition has occurred
• Output 3: Printer is busy: The printhead is out in its printing position
• Spare Output: Not Available for Use.
ICE Pegasus Service Manual
