Videojet 6210 Service Manual
Rev AA Working with Printer Connections 3-15
Interlocks and Annunciation
The 15-pin D-type (male) connector, located on the side of the printer unit
is available for connecting with a variety of useful interlock and
annunciation signals.
Table 3-2 summarizes the input and output connections.
Note: For more information on configuring the inputs and outputs, refer
“Working with the Inputs and Outputs” on page 3-25.
Pin Purpose
1 +24 V
2 External input #1 PNP 24 V
30 V
4 External input #2 PNP 24 V
5 Not Used
6 Relay output #1 N/C
7 Relay output #1 common
8 Relay output #1 N/O
9 Relay output #2 common
10 Relay output #2 N/O
11 PNP 24 V Output #1
12 0 V
13 Not Used
14 Encoder Phase B input
15 Encoder Phase A input
Table 3-2: Input and Output Connections
