Rev AA Configuring the Printer 3-21
access to the printer, while line operators are limited to accessing only the
operating variables that are relevant to them.
Installing the CLARiTY Configuration Manager
To install the CLARiTY Configuration Manager on a PC, insert the
CLARiTY Configuration Manager CD-ROM. The installation routine
commences automatically. Follow the on-screen instructions to install the
software.
If your PC has the auto run facility disabled, the installation routine will
not start automatically. To enable the installation procedure, proceed as
follows:
1 Click the Start button.
2 Click the Run button to open a dialog box.
3 Type “D:\setup.exe” in the dialog box and press enter/return key.
Note: D: is the drive letter of the PC's CD-ROM drive. If it is different for
your PC, replace the letter D with the appropriate drive letter.
The software is installed in the PC and is ready for use.
Connecting the CLARiTY Configuration Manager to the Printer
Connecting CLARiTY Configuration Manager to the Printer using an
RS 232 connection
To connect the CLARiTY Configuration Manager to the printer, proceed
as follows:
1 Connect the PC serial port to the CLARiTY controller using the null-
modem cable.
Ensure that all other programs (such as, Active sync and other PDA
applications) that use the serial port are disabled.
