3-24
Configuring the Printer
Rev AA
CLARiTY panel. It may be more convenient to make final adjustments at
the panel rather than using the CLARiTY Configuration Manager.
Saving the Changes in the Printer
To make the changes effective, proceed as follows:
1 Click the printer icon in the left-hand pane to open the printer controls
at the bottom pane of the window.
2 Click the download button to update the printer with the changes that
you have made to the parameters.
A dialog box opens with the message “The parameters to be
downloaded have not been saved to an archive”.
3 Touch OK to continue with the download.
4 The new parameters are active when the download is complete.
Note: Unless steps 1 to 4 are performed, none of the parameter changes
become effective in the printer.
Archiving the Current Parameters
The set of parameters can be saved as an archive and are stored on the PC.
The archive can be loaded into the Configuration Manager and
downloaded to the printer again at a later date to revert to the archived set
of parameters.
Once the printer has been configured, it is recommended that all the
parameters be uploaded into the PC, and saved as an archive.
To archive the current parameters, proceed as follows:
1 Right click the Archives folder in the left-hand panel.
2 Select the New Save option from the pop-up menu.
A file for the new save appears under the archives folder with a name
containing the current time and date.
3 Change the name of the archive in the bottom panel, and click the
Apply button.
ICE Pegasus Service Manual
