Rev AA Maintaining the Printer 5-19

4 Touch the Printhead button to open the Printhead Setup Page.

5 Select the Printhead Resistance parameter and enter the resistance

value that was displayed on the printhead label (Figure 5-24).

6 Use the arrows or the keypad to set the settings and touch OK to save

the settings.

7 A confirmation message is displayed to ensure that this parameter is

not changed inadvertently. Choose 'Yes' to proceed to set the new

value.

Maintaining the Cassette

Replacing the Cassette Rollers

To replace the cassette rollers, proceed as follows.

1 Remove the cassette from the printer.

2 Remove the ribbon from the cassette.

Figure 5-24: Printhead Resistance Setting

CE Pegasus Service Manual
