Videojet 6210 Service Manual

Rev AA Cassette Assembly 8-7

Cassette Assembly

Table 8-5 lists the parts of the cassette assembly.

Item Number P/N Description Qty

C Cassette Assembly

(Refer to Figure 8-5)

11 403327 Silver Disc - Pack 5 off

12 403323 53mm Cassette Roller Set of 6

13 Print Ribbon

(Refer to Table 8-7 on page 8-9

for details)

14 403326 Black Disc - Pack 5 off

Table 8-5: Parts of Cassette Assembly

Figure 8-5: Cassette Assembly
