Rev AA Electrical Wiring Schematics 9-6
Table 9-1 lists the different wire colors and their corresponding functions.
X16
Pin #
Wire
Color
Function Factory Default
1Red (Brown on
ENC lead)
+24V +24V
2 Blue External input #1 PNP 24V Print input from host machine
3 Green 0V 0V
4 Black External input #2 PNP 24V Inhibit print from host machine
5 White External input #3 PNP 24V Spare input-not used
6 Orange External relay output #1 Fault relay N/C
7 White/Black External relay output #1 Fault relay COMMON
8 Red/Black External relay output #1 Fault relay N/O
9 Green/Black External relay output #2 Warning relay COMMON
10 Orange/Black External relay output #2 Warning relay N/O
11 Blue/Black External PNP output #3 PNP 24V BUSY
12 Black/White (Black
on ENC)
0V 0V
13 Red/White External PNP Output #4 PNP 24V Spare-not used
14 Green/White
(White on ENC
lead)
Encoder phase B signal input (24V push/pull preferred or open collector compatible)
15 Blue/White (Blue
on ENC lead)
Encoder phase A signal input (24V push/pull preferred or open collector compatible)
Table 9-1: List of the Wire Colors for Videojet 6210 Printer Electrical Schematic
ICE Pegasus Service Manual
