Icom IC-7610 Advanced Manual

8
2. ADVANCED OPERATIONS
Resetting all band edges to presets
The steps below will reset all the band edges to their
initial settings. All entered settings will be deleted.
1. Display the “User Band Edge” screen.
2. Touch any band edge for 1 second.
3. Touch “Default.”
• Displays “Reset All Edges?”
4. Touch [YES].
• All the band edges will be reset to the initial settings.
Band Edge Beep (continued)

Icom IC-7610 Specifications

General

Receiver Type	Direct sampling
Number of Antenna Connectors	2
Type	HF/50 MHz Transceiver
IF DSP	Yes
Antenna Connector	SO-239
Frequency Range	0.030–60.000 MHz
Power Supply	13.8 V DC ±15%
Modes	AM, FM
RF Output Power	100 W
Display	7-inch color
Weight	8.5 kg
External Speaker Connector	3.5 mm
USB Connector	Type B
Output Power	100 W
Operating Temperature	-10°C to +60°C
