37
2. ADVANCED OPERATIONS
About the 5 MHz frequency band operation (USA version only)
Operation on the 5 MHz frequency band is allowed
on 5 discrete frequencies and you must adhere to the
following:
The USB, USB Data, PSK, and CW modes.
Maximum of 100 watts ERP (Effective Radiated
Power)
Maximum 2.8 kHz bandwidth
It is your responsibility to set all controls so that
transmission in this frequency band meets the
stringent conditions under which amateur operations
may use these frequencies.
TIP: We recommend that you save these

channels, for easy recall.
NOTE: 
by the FCC, transmission is illegal on any frequencies

For the USB and USB data modes:

frequency band. However, the transceiver displays
carrier frequency. Therefore, tune the transceiver

frequency.
Transceiver displayed
frequency
FCC channel center
frequency
5.33050 MHz 5.33200 MHz
5.34650 MHz 5.34800 MHz
5.35700 MHz 5.35850 MHz
5.37150 MHz 5.37300 MHz
5.40350 MHz 5.40500 MHz
For the CW and PSK modes:
The transceiver displays the center frequency.

channel frequency when you operate in these modes.
Transceiver displayed
frequency
FCC channel center
frequency
5.33200 MHz 5.33200 MHz
5.34800 MHz 5.34800 MHz
5.35850 MHz 5.35850 MHz
5.37300 MHz 5.37300 MHz
5.40500 MHz 5.40500 MHz
