Icom IC-7610 Advanced Manual

43
4. VOICE RECORDER FUNCTIONS
Playing back a QSO audio

1. Insert the SD card in which the recorded audio is
saved.
 
MENU
» RECORD > Play Files
3. Select the folder that the file you want to playback
is saved.
4. Select the file to play back.
• Starts a playback.
L

5. 
EXIT
several times.
Recording start
time and date

The TX/RX status
of the recorded
audio.
Play back
icon
Play back
time
Total timePlay back
process
Operating frequency, operating
mode, of the Main and Sub bands.
Play the

Pause/
Playback
Play the

Rewind Forward

Icom IC-7610 Specifications

General

Receiver Type	Direct sampling
Number of Antenna Connectors	2
Type	HF/50 MHz Transceiver
IF DSP	Yes
Antenna Connector	SO-239
Frequency Range	0.030–60.000 MHz
Power Supply	13.8 V DC ±15%
Modes	AM, FM
RF Output Power	100 W
Display	7-inch color
Weight	8.5 kg
External Speaker Connector	3.5 mm
USB Connector	Type B
Output Power	100 W
Operating Temperature	-10°C to +60°C
