Icom iC-M605 - Page 53

43
8
DSC OPERATION
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
D Sending a Test call
Testing on the exclusive DSC distress
and safety calling channels should be
avoided as much as possible by using
other methods.
Normally the Test call would require no
further communications between the
two stations involved.
1. Push [
Compose Other] to
display the COMPOSE NON-
DISTRESS screen.
L To display the screen from the Menu
screen:
([MENU] > Compose Non-Distress )
2. Select “Message Type,” then
push [ENT].
3. Select “Test.”
4. Select “Address,” then push [ENT].
5. Select the Individual address, or
“Manual Input.”
(Example: STATION1)
When you select “Manual Input” in step
5, push the keypad to manually enter
the Individual ID. (p. 25)
6. Push [Call] to send the Test call.
Push
7. After sending, the following screen
is displayed.
L See page 29 or page 30 for
details of the Task mode’s Software
key functions.
+
Push
Rotate
+
Push
Rotate
