96
14
SPECIFICATIONS AND OPTIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Specifi cations
General D
• Frequency coverage
Tx 156.025–157.425 MHz
Rx 156.050–163.275 MHz (USA and EXP versions)
Rx 156.300–162.025 MHz (AUS version)
• Mode :
FM (16K0G3E), DSC (16K0G2B)
Operating temperature range
USA and EXP versions :
–20°C to +60°C (–4°F to +140°F)
AUS version : –10°C to +55°C
Current drain (at 7.4 V) : TX high 1.5 A
(approximately) Max. audio 0.5 A
Power supply requirement :
7.4 V DC nominal (negative ground)
• Frequency stability
USA and EXP versions : ±10 ppm (–20°C to +60°C)
AUS version : ±10 ppm (–10°C to +55°C)
Antenna impedance : 50 ˘ nominal
Dimensions (approximately) :
61.2(W) 141.4(H) 43.2(D)mm
(Projections not included) : 2.4(W)
5.6(H) 1.7(D) inches
Weight (approximately) : 287 g/10.1 oz with BP-275
Transmitter D
Output power
USA and EXP versions : 5 W/1 W
AUS version : 5 W (approximately)/1 W
• Modulation system : Variable reactance frequency
modulation
Max. frequency deviation : ±5.0 kHz
Adjacent channel power : 70 dB
Spurious emissions (typical)
USA and EXP versions : –68 dBc
AUS version : 0.25 µW
Receiver D
• Sensitivity (typical)
USA and EXP versions : 0.25 µV (12 dB SINAD)
AUS version : –5 dBµ emf (20 dB SINAD)
Squelch sensitivity (at threshold, typical)
USA and EXP versions : 0.35 µV
AUS version : –6 dBµ emf
Intermodulation rejection ratio
USA and EXP versions : 70 dB (typical)
AUS version : 65 dB
Spurious response rejection ratio
:
USA and EXP versions : 70 dB (typical)
AUS version : 65 dB
Adjacent channel selectivity :
USA and EXP versions : 70 dB (typical)
AUS version : 65 dB
Audio output power (at 10% distortion with an
8 ˘ load)
USA and EXP versions
:
0.35 W typical (External)
: 0.7 W typical (Internal)
AUS version : 0.2 W (External)
: 0.7 W typical at 1 kHz (Internal)
All stated specifi cations are subject to change without notice
or obligation.
