9
3
PANEL DESCRIPTION
Softkey function
Various functions can be assigned to the softkeys.
When the key function is assigned, the key icon is displayed
above the softkeys, as shown below.
Softkey function selection D
When “Ω or “ is displayed beside the key icon, pushing [Ω]
or [] sequentially displays the previous or next key function
that is assigned to the softkey.
Push Push
*Push this key to start or stop a scan.
*
The order of the key icons may differ, depending on the
preprogramming.
Function Display (Continued)
!5 POSITION INDICATOR
Shows the current position when valid GPS data is re-
ceived or the position is manually programmed.
“??” will blink when invalid GPS data is received for 30
seconds.
??” will blink when manually input GPS data is no longer
valid after 4 hours, and then NO POSITION” will appear
after 23.5 hours.
NO POSITION” is displayed when no GPS data is received
since the transceiver power turned ON.
NO POSITION” appears when no GPS data is received,
and no position is manually input.
!6 SCAN INDICATOR
“SCAN 16” is displayed during a Priority scan; “SCAN”
appears during a Normal scan. (p.
17)
“DUAL 16” appears during Dualwatch; “TRI 16” appears
during Tri-watch. (
p. 19)
!7 BATTERY INDICATOR
Shows the battery’s remaining power.
Indication
Full Middle
Charging
required
No battery
Battery level
blinks when the battery is over charged.
