2: P RODUCT S PECIFICATIONS
2-64 FC6A S ERIES M ICRO S MART A LL - IN -O NE T YPE U SER ’ S M ANUAL FC9Y-B1722
Model List
Power Supply Specifications
*1 The value when the input is not open and the output is 100% output.
Module type Cable Terminal Type I/O Points I/O Signal Type No.
Analog Input
module
Terminal block type (5.08 mm pitch)
Input
2
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
FC6A-J2C1
Terminal block type (3.81 mm pitch) 4
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
FC6A-J4A1
Terminal block type (3.81 mm pitch) 8
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
FC6A-J8A1
Terminal block type (3.81 mm pitch) 4
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
Thermocouple (K, J, R, S, B, E, T, N, C)
Resistance thermometer (Pt100, Pt1000,
NI100, NI1000)
FC6A-J4CN1
Terminal block type (3.81 mm pitch) 8
Thermocouple (K, J, R, S, B, E, T, N, C)
Thermistor (PTC, NTC)
Resistance (100 to 32,000 Ω)
FC6A-J8CU1
Analog output
module
Terminal block type (5.08 mm pitch) Output 4
Voltage output (0 to 10 V, -10 to +10 V)
Current output (4 to 20 mA, 0 to 20 mA)
FC6A-K4A1
Mixed analog I/O
module
Terminal block type (5.08 mm pitch)
Input 2
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
Thermocouple (K, J, R, S, B, E, T, N, C)
Resistance thermometer (Pt100, Pt1000,
NI100, NI1000)
FC6A-L03CN1
Output 1
Voltage output (0 to 10 V, -10 to +10 V)
Current output (4 to 20 mA, 0 to 20 mA)
Terminal block type (3.81 mm pitch)
Input 4
Voltage input (0 to 10 V, -10 to +10 V)
Current input (4 to 20 mA, 0 to 20 mA)
FC6A-L06A1
Output 2
Voltage output (0 to 10 V, -10 to +10 V)
Current output (4 to 20 mA, 0 to 20 mA)
Type No. FC6A-J2C1 FC6A-J4A1 FC6A-J8A1 FC6A-J4CN1 FC6A-J8CU1 FC6A-K4A1 FC6A-L03CN1 FC6A-L06A1
External
Power
Power Supply
Voltage
24V DC
Allowed
Fluctuation
Range
20.4 to 28.8V DC
Terminal Arrangement 2-71 2-72 2-72 2-73 2-73 2-74 2-74 2-75
Connector
module
Insertion/
Removal
Durability
100 times minimum
Internal
Current
Draw
5V DC 40 mA 45 mA 40 mA 50 mA 45 mA 50 mA 60 mA 55 mA
24V DC 0 mA 0 mA 0 mA 0 mA 0 mA 0 mA 0 mA 0 mA
Module External Power
Supply Current Draw
*1
25 mA
(24V DC)
30 mA
(24V DC)
40 mA
(24V DC)
40 mA
(24V DC)
30 mA
(24V DC)
125 mA
(24V DC)
80 mA
(24V DC)
100 mA
(24V DC)
