Idis TR-4316 - Tripzone

Part 2 - Conguration
39
• Min. Blocks: Motion needs to be detected in more
than the specied number of blocks in order to
trigger a Motion Detection event. You may select a
value between 1 and the number of blocks selected
under Zone for daytime and nighttime, each.
• Zone View: Allow you to observe how the DVR is
reacting to motion. When in the motion viewing
mode, the detection zone of video will be displayed.
Any detected motion within the zone will be
displayed in red.
• Motion Ignoring Time: The system does not produce
event log entries or issues remote notications
regarding motion detected during the specied time
following the initial motion detection. Set a value
between 1 sec and 10 secs or choose Never.
Motion Ignoring Time does not aect motion
detection recording.
• Actions: Specify which actions to take when motion
is detected.
– Record: Specify which cameras to begin linked
recording on when an event occurs. If the schedule
is set to Event or Time & Event mode, the selected
cameras will begin linked recording when an event
occurs.
– Alarm-Out: Designate event-triggered alarm-out
channels and beeps.
– Notify: Congure to be notied of events by Mail,
LAN1 through 5, FTP, Push, and/or Alert Window.
– PTZ: Moves the PTZ camera to a specic preset
position when an event occurs.
In order to use the Callback feature, the DVR must be
registered on the remote program.
• Daytime Setup: Specify when daytime starts and
ends. Adjust the time frame in 15-minute increments.
Times outside the specied range will be assumed as
nighttime by the system.
Tripzone
• No.: Select which cameras to apply Tripzone
Detection to.
• Sensitivity: Set daytime and nighttime sensitivity
settings between 1 (Low) and 5 (High).
• Zone: Dene the motion detection block.
