8 Applications
Test images marked (RAW) are only properly displayed in raw Bayer mode (see Color).
Figure 87: Selecting test images
(here: UI-5480-C)
§ Parameter value
You can adjust the appearance of some of the test images with the Parameter value slider.
Animated test images are ideal for testing recorded sequences.
With some sensors, the sensor gain setting has an influence on the test image.
For USB cameras, you can use a white test image to check the camera's maximum load
on the USB bus. Due to the transmission process, completely white camera images
require a somewhat more bandwidth on the USB bus than completely black images.
· Default
Click this button to reset all parameters to the model-specific defaults.

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
