© 2009 IDS Imaging Development Systems GmbH212
User Manual uEye Cameras V3.32
9.4 Status LED
9.4.1 USB uEye
USB uEye SE/RE
The LED on the rear side of the USB uEye camera indicates whether
· the uEye camera is powered on – LED lights up red (only USB board rev. 2.0 or higher).
· the uEye driver has been loaded and the camera is operational – LED lights up green
· an error has occurred – green LED flashes:
§ 2x flash: unknown sensor, please contact our support team.
If the LED does not light up green, please check the following:
· Has the camera been connected correctly?
· Have the driver and the camera been installed properly in the uEye Camera Manager on the host
PC?
· Does the host PC meet all system requirements?
Figure 203: USB uEye SE
status LED (rev. 1.2)
Figure 204: USB uEye SE status LED (rev.
2.0)
USB uEye LE
The USB uEye LE camera has a single color status LED. It lights up orange as soon as the camera
is supplied with power.
