IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH 67
8 Applications
8.2.2 Toolbars
uEye
1
Open camera and start in live mode
2
Open camera
3
Close camera
4
Camera changes to standby mode
5
Save image as bitmap
6
Open the dialog box for AVI Recording
7
Copy image to the Clipboard (only in DIB mode)
8
Test the range of camera functions
9
Select AOI (Area Of Interest)
10
Delete selected AOI
11
Open/close Histogram window
12
Open/close Horizontal Line View window
Displays the color values of a pixel row
13
Open/close Vertical Line View window
Displays the color values of a pixel column
14
Open/close Zoom window
15
Open/close Pixel Peek window
Display
1
Deactivate display
2
Full screen window in overlay or back buffer mode
3
Scale display to window size
4
Display at original size
5
Scale display down to half size
6
Scale display down to quarter size
7
Scale display up to double size
8
Limit max. display frame rate to 30 fps.
The image capture frame rate remains unchanged.

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
