IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH 177
9 Specifications
Adjusting the Flange Back Distance
Some uEye models feature an adjusting ring that allows changing the flange back distance. Please
follow the information below to avoid damage to the camera.
USB uEye LE
The adjusting ring of the USB uEye LE has 10 adjusting positions. For each adjusting position, the
flange back distance is altered by +/- 50 µm.
To change the position of the adjusting ring, please proceed exactly in the following
order:
1.
Loosen the locking screw (see figure below).
2.
Adjust the C-mount ring (IDS special tool required, see USB uEye LE
Accessories).

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
