IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH 117
9 Specifications
9.1.1 CMOS Cameras
UI-122x / UI-522x
Sensor specification
Sensor type
CMOS
Shutter system
Electronic global shutter
Readout mode
Progressive scan
Resolution class
WVGA
Resolution
752 x 480 pixels (0.36 Mpixels)
Aspect ratio
14:9
Bit depth
10 bits
Optical sensor class
1/3 inch
Exact sensitive area
4.51 mm x 2.88 mm
Exact optical sensor diagonal
5.4 mm (1/3.0 inch)
Pixel size
6.0 µm, square
Sensor name, monochrome
Micron MT9V032C12STM
Sensor name, color
Micron MT9V022I77ATC
Sensor name, color (USB uEye LE)
Micron MT9V032C12STC
Gain
Monochrome model (master gain)
4.0x
Color model (master/RGB)
4.0x/5.0x (software)
Offset control, mode
Auto/manual, additive
Gain boost
1.6x
Camera timing
USB uEye
GigE uEye SE
GigE uEye HE
Pixel clock range
MHz
5-40
*1)
5-42
*1)
5-46
*1)
Pixel clock range (with subsampling/binning)
MHz
5-60
*1)
5-59
*1)
5-60
*1)
Frame rate (freerun mode)
fps
87
*2)
91.5
*2)
100
*2)
Frame rate (trigger mode, 1 ms exposure)
fps
75
*2)
60
*2)
75
*2)
Exposure time in freerun mode
ms
0.08
*2)
-5500
*3)
0.076
*2)
-5500
*3)
0.07
*2)
-5500
*3)
Exposure time in trigger mode
ms
0.08
*2)
-5500
*3)
0.076
*2)
-5500
*3)
0.07
*2)
-5500
*3)
AOI
Mode
Horizontal
*4)
+ Vertical
*4)
AOI image width, step width
Pixels
16-752, 4
16-752, 4
16-752, 4
AOI image height, step width
Pixels
4-480, 2
4-480, 2
4-480, 2
AOI position grid horizontal, vertical
Pixels
4, 2
4, 2
4, 2
AOI frame rate, 640 x 480 pixels (VGA)
fps
100
105
115
AOI frame rate, 320 x 240 pixels (CIF)
fps
200
211
231
AOI frame rate, 160 x 120 pixels
fps
344
344
390
Binning
