IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH118
User Manual uEye Cameras V3.32
Mode
Horizontal
*4)
+ Vertical
*4)
Method
H + V: Monochrome binning, averaging
Frame rate with 2x binning, 376 x 240 pixels
fps
238
234
238
Frame rate with 4x binning, 188 x 120 pixels
fps
407
400
407
Subsampling
Mode
-
H + V
H + V
Method
-
Mono/color
subsampling
Mono/color
subsampling
Frame rate w/ 2x subsampling, 376 x 240
pixels
fps
-
91
100
Frame rate w/ 4x subsampling, 188 x 120
pixels
fps
-
91
100
Hardware trigger
Mode
Asynchronous
Asynchronous
Asynchronous
Trigger delay with rising edge
µs
19.7 ±0.25
< 5
< 5
Trigger delay with falling edge
µs
38.0 ±0.25
< 5
< 5
Additive trigger delay (optional)
µs
15 µs-4 s
15 µs-4 s
15 µs-4 s
Sensor delay to exposure start
µs
< 200
*2)
< 200
*2)
< 200
*2)
Connected load
*5)
USB uEye
GigE uEye SE
GigE uEye HE
W
0.4-1.0
2.3-3.1
2.9-4.2
*1)
The maximum possible pixel clock frequency depends on the PC hardw are used.
*2)
Requires maximum pixel clock frequency.
*3)
Requires minimum pixel clock frequency.
*4)
Use of this function increases the frame rate.
*5)
The connected load depends on the sensor model and the pixel clock setting.

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
