© 2009 IDS Imaging Development Systems GmbH56
User Manual uEye Cameras V3.32
8.1.4 Camera Information
In the Camera information dialog box, you can assign a unique ID to the selected camera and write
to the user area of the EEPROM. The data you enter is retained in the camera memory even when
the camera is disconnected from the PC or power supply.
Figure 55: uEye Camera Manager –
Camera information
You can only set the camera ID and write to the EEPROM if the camera is marked Free and
Available in the Camera Manager (see also Camera list).
· Camera ID
The camera ID identifies a camera in multi-camera operation. You can assign IDs in a range from
1 to 254. The default value for the camera ID is 1. The same ID can be assigned to multiple
cameras. You do not have to assign sequential ID numbers to all connected cameras.
If software accesses the camera through the uEye DirectShow interface, the camera ID
must be in a range from 1 to 8.
· User EEPROM (max. 64 characters)
Every uEye has a 64-byte user area in its EEPROM (Electrically Erasable and Programmable
Read Only Memory) to which you can write text of your choice.
The Camera information dialog box displays two additional boxes that are for your information only
and cannot be edited:
§ Manufacturer (e.g. IDS GmbH)
§ Date of QC (date of final camera quality test)
8.1.5 Creating a Support File
A uEye support file is a binary file with the extension .bin. The file contains camera and
driver details that are required for diagnostics by the uEye support team. No personal
computer data or user data is stored in this file.
The button opens the "Save as" dialog box, where you can save the
displayed camera information and additional driver information to a file.
