9 Specifications
UI-241x / UI-641x
Sensor specification
Sensor type
CCD
Shutter system
Electronic global shutter
Readout mode
Progressive scan
Resolution class
VGA
Resolution
640 x 480 pixels (0.31 Mpixels)
Aspect ratio
4:3
Bit depth
12 bits
Optical sensor class
1/3 inch
Exact sensitive area
4.74 x 3.55 mm
Exact optical sensor diagonal
5.9 mm (1/2.7 inch)
Pixel size
7.4 µm, square
Sensor name, monochrome
Sony ICX424AL
Sensor name, color
Sony ICX424AQ
Gain
Monochrome model (master gain)
18.0x
Color model (master/RGB)
12.0x/4.0x
Offset control, mode
Auto/manual, additive
Gain boost
2.0x (monochrome model only)
Camera timing
USB uEye
GigE uEye SE
GigE uEye HE
Pixel clock range
MHz
5-30
*1)
5-30
*1)
5-30
*1)
Pixel clock range (with subsampling/binning)
MHz
5-30
*1)
5-30
*1)
5-30
*1)
Frame rate (freerun mode)
fps
75
*2)
75
*2)
75
*2)
Frame rate (trigger mode, 1 ms exposure)
fps
64
*2)
64
*2)
64
*2)
Exposure time in freerun mode
ms
0.04 *
2)
-640
*3)
0.04 *
2)
-640
*3)
0.04 *
2)
-640
*3)
Exposure time in trigger mode
ms
0.04 *
2)
-10 min
*3)
0.04 *
2)
-10 min
*3)
0.04 *
2)
-10 min
*3)
AOI
Mode
Horizontal + Vertical
*4)
AOI image width, step width
Pixels
16 - 640, 4
16 - 640, 4
16 - 640, 4
Mono: AOI image height, step width
Pixels
120 - 480, 1
120 - 480, 1
120 - 480, 1
Color: AOI image height, step width
Pixels
120 - 480, 2
120 - 480, 2
120 - 480, 2
Mono: AOI position grid horizontal, vertical
Pixels
1, 1
1, 1
1, 1
Color: AOI position grid horizontal, vertical
Pixels
2, 2
2, 2
2, 2
AOI frame rate, 320 x 240 pixels (CIF)
fps
111
111
111
Binning
Mode
Vertical
*4)
Horizontal +
Vertical
*4)
Horizontal +
Vertical
*4)
Method
V: Monochrome
H + V:
H + V:
