© 2009 IDS Imaging Development Systems GmbH180
User Manual uEye Cameras V3.32
Figure 160: Position accuracy of the sensor
Position accuracy inside the camera
housing, in each direction
±0.3
mm
Horizontal/vertical rotation (a)
±1.0
°
Translational rotation (b)
±1.0
°
Flange back distance
±0.05
mm
C-mount lenses can also be subject to inaccuracies of the flange back distance. The
tolerance usually is ±0.05 mm. In some cases, however, the inaccuracies of camera and
lens might add up, resulting in a total error > 0.05 mm.
