IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH 217
10 Accessories
Figure 209: USB uEye SE angled D-Sub connector
USB uEye SE USB accessories
Purchase Order No.
Description
AL.0094.2.01900.00
EX-1200 USB 2.0 high speed PCMCIA card, 2 ports, NEC chipset
AL.0094.2.02500.00
EX-1074 USB 2.0 high speed PCI card, 4 ports, NEC chipset
AL.0094.2.02400.00
EX-1171 USB 2.0 hub, metal housing, 7 ports
AL.0094.2.02100.00
EX-1171 USB 2.0 hub, 7 ports
AL.0094.2.02200.00
EX-1163 USB 2.0 hub, 4 ports
AL.0094.2.02300.00
USB 2.0 active expansion cable, 5 m (single port)
Tripod adapter for USB uEye SE
Purchase Order No.
Description
AL.0012.2.01300.00
Tripod adapter for USB uEye SE series (4 screws included)

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
