IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH72
User Manual uEye Cameras V3.32
uEye
Initialize
Open camera and show live image
Initialize and stop
Open camera
Standby
The camera changes to standby mode
Close
Close camera
Reset to defaults
Resets all values set in the demo program to the defaults
Live
Live video on/off
Snap
Snapshot from live video
Sync Trigger (Rising Edge)
Triggered snapshot (hardware trigger, rising edge)
Sync Trigger (Falling Edge)
Triggered snapshot (hardware trigger, falling edge)
Trigger snap
Triggered snapshot (software trigger)
Trigger mode ...
Trigger mode on/off; continuous triggered capture
Properties
See Camera Properties
Auto contrast
Activate automatic brightness control
Set new AES/AGC AOI
Define active area for automatic brightness control
Clear AES/AGC AOI
Clear active area defined for automatic brightness control
Auto whitebalance
Activate automatic white balance
Set new AWB AOI
Define active area for automatic white balance
Clear AWB AOI
Clear active area defined for automatic white balance
Set new AOI
After calling Set new AOI, you can select the area to be used as

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
