5.2.13 MCU Connector (TS2)
5.2.14 PCIe Mini Slot (CN2)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 PCIE_WAKE# 2 VCC3
3 RESERVED 4 GND
5 RESERVED 6 1.5 V
7 CLKREQ# 8 N/C
9 GND 10 N/C
11 REFCLK- 12 N/C
13 REFCLK+ 14 N/C
15 GND 16 N/C
17 N/C 18 GND
19 N/C 20 N/C
21 GND 22 PERST#
23 PERn0 24 VCC3_AUX
25 PERp0 26 GND
27 GND 28 1.5 V
29 GND 30 SMBCLK
31 PETn0 32 SMBDATA
33 PETp0 34 GND
35 GND 36 USBD-
PIN NO. DESCRIPTION
1 AUTO_DIMMING
2 LOCK_BUTTON
3 VOL+
4 VOL-
5 BRIGHT+
6 BRIGHT-
7 LCD_ON_OFF
8 GND
Table 5-14: MCU Connector (TS2) Pinouts
