PIN NO. RS-232 RS-422 RS-485
4 NDTR3
5 GND
6 NDSRB RX-
7 NRTSB RX+
8 NCTS3
9 COM_RI3
10 GND
Table 5-28: COM3 Connector Pinouts
5.3.5 SATA Connector (SATA2)
5.3.6 USB 2.0 Connectors (USB3)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 +5Vsus 5 +5Vsus
2 D4F- 6 D5F-
3 D4F+ 7 D5F+
4 GND 8 GND
Table 5-30: USB 2.0 Connectors (USB3) Pinouts
PIN NO. DESCRIPTION
1 GND
2 STXP_0
3 STXN_0
4 GND
5 SRXN_0
6 SRXP_0
7 GND
7 GND
7 GND
Table 5-29: SATA Connector (SATA2) Pinouts
