Page 77
NOTE: Make sure the selected COM port is enabled through the Super I/O configuration
menu.
Î Base Address, IRQ [3F8h,4]
The Base Address, IRQ option cannot be configured and only shows the interrupt
address of the serial port listed above.
Î Serial Port Mode [115200 8,n,1]
Use the Serial Port Mode option to select baud rate through which the console redirection
is made. The following configuration options are available
 115200 8,n,1 D
EFAULT
 57600 8,n,1
 38400 8,n,1
 19200 8,n,1
 09600 8,n,1
NOTE:
Identical baud rate setting musts be set on the host (a management
computer running a terminal software) and the slave
Î Redirection After BIOS POST [Always]
Use the Redirection After BIOS POST option to specify when console redirection should
occur.
Î
Disabled
The console is not redirected after POST
Î
Boot Loader
Redirection is active during POST and during Boot
Loader
Î
Always DEFAULT
Redirection is always active (Some OSes may not
work if set to Always)
