IEI Technology AFL-08B-N270 User Manual

AFL-08B-N270 User Manual
Page 20
Specifications AFL-08B-N270
Audio
AMP 1.5 W + 1.5 W internal speakers
Digital microphone
Digital Camera
2-megapixel digital camera on the front panel
Wireless LAN
Wireless LAN 802.11 b/g/n PCIe Mini card module
Bluetooth V2.0
Optional
Construction Material
ABS + PC Plastic front frame
LED Function
One power on/off LED on the front panel
Mounting
Panel, Wall, Rack, Arm, Stand (VESA 75mm x 75mm)
Front Panel Color
Grey 7539U
Dimension (W x H x D) (mm)
234 x 177 x 43
Operation Temperature (ºC)
-10ºC~50ºC
Storage Temperature (ºC)
-20ºC~60ºC
Net Weight
0.8 Kg
IP Level
Front Frame IP64
EMC
CE, FCC, CCC
Safety
CB
Touch Screen
Resistive 5-Wire
Power Adapter
36 W power adapter
Input: 100 V AC ~ 240 V A
C; 50 Hz ~ 60 Hz
Output: 12 V DC
Power Requirement
12 V DC
Power Consumption
25 W
Table 1-1: AFL-08B-N270 Specifications
1.6 Dimensions
The AFL-408A/B-N270 dimensions are listed below and shown in the following figure.
 Width: 234 mm
