AFL-08B-N270 User Manual
Page 19
1.5 System Specifications
The technical specifications for the AFL-08B-N270 systems are listed below.
Specifications AFL-08B-N270
LCD Size
8"
Max Resolution
800 x 600
Brightness (cd/m2)
300
Contrast Ratio
400:1
LCD Color
262K
Pixel Pitch (mm)
0.0675(H) x 0.2025(V)
Viewing Angle (H-V)
130º/120º
Backlight MTBF
30000 hrs
CPU
Intel® Atom™ N270 1.6 GHz CPU
Chipset
Intel 945GSE + ICH7M
RAM
1 GB 533 MHz DDR2 SO-DIMM
Supports one 400 MHz or 533 MHz DDR2 SO-DIMM (2 GB
Max.)
Audio Codec
Realtek ALC892
I/O Ports and Switches
One 12V DC power jack
One Audio line-out jack
One External SATA port
One Power switch
One Reset button
Two RJ-45 GbE LAN ports
One RS-232 serial port
One RS-232/422/485 serial port
Two USB 2.0 ports
SSD
CF Type II
Watchdog Timer
Software programmable supports 1~255 sec. System reset
