AFL-08B-N270 User Manual
Page 27
Hybrid card reader
(P/N: AFLP-08AMSI-U)
Magnetic stripe reader
(P/N: AFLP-08AMSR-U)
60 W DC/DC 9-30 VDC input vehicle power adapter:
IDD-930160-KIT
DC 12 V Input UPS
AUPS-A10-R10
DC 9-36V Input UPS
AUPS-A20-R10
Make sure all the components listed in the packing list are present. If any of these items
are missing or damaged, contact the distributor or sales representative immediately.
2.2 Removing the Rear Panel
To access the AFL-08B-N270 internally the rear panel must be removed. To remove the
rear panel, please follow the steps below.
Step 1: Remove the retention screws (
Figure 2-1).
