AFL-08B-N270 User Manual

Page 108

5.4.3 LVDS Panel Voltage Selection Jumper (J_VLVDS1)

Pin Description

Short 1-2 +3.3 V (Default)

Short 2-3 +5 V

Table 5-34: LVDS Voltage Selection Jumper (J_VLVDS1) Settings

5.4.4 MCU LCD Type Selection Jumper (JP14)

Pin Description

Short 1-3 LCD Panel (Default)

Short 2-4 LED Panel

Table 5-35: MCU LCD Type Selection Jumper (JP14) Settings

5.4.5 MCU PWM Power Selection Jumper (JP13)

Pin Description

Short 1-2 +5V (Default)

Short 2-3 +3.3V

Table 5-36: MCU PWM Power Selection Jumper (JP13) Settings

5.4.6 Panel Type Selection Jumper (J_LCD_TYPE1)

Pin Description Pin Description

1 PA_DGPI0 2 GND

3 PA_DGPI1 4 GND

5 PA_DGPI2 6 GND

7 PA_DGPI3 8 GND

Table 5-37: Panel Type Selection Jumper (J_LCD_TYPE1) Settings
