AFL-08B-N270 User Manual

Page 109

5.4.7 Touchscreen Selection Jumper (J1)

Pin Description

Short 1-2 5-wire (Default)

Short 3-4 4-wire

Table 5-38: Touchscreen Selection Jumper (J1) Settings

5.4.8 USB2 and USB4 Power Selection Jumper (JP15)

Pin Description

Short 1-3 USB4 +3.3V

Short 3-5 USB4 +5V (Default)

Short 2-4 USB2 +3.3V

Short 4-6 USB2 +5V (Default)

Table 5-39: USB2 and USB4 Power Selection Jumper (JP15) Settings
