Ihse Draco compact DVI 477 Series User Manual

Description
2021-07-09 29
3.7.4 Status VGA / DVI-I (Option)
The KVM Extender with VGA / DVI-I input is fitted with a multi-color LED
on the front side of the CPU Unit for indication of connection status.
Further information are available via on screen display (OSD) (see manual
for the Media / DVI Converter K238-5V (Download)).
CP
U Unit
Front View
LED 1: Connection Status VGA / DVI-I
LED color
Description
Dark Red No video signal; monitor not detected
Red Video signal not supported; monitor not detected
Green Video signal supported; monitor not detected
Blue No video signal; monitor detected
Violet Video signal not supported; monitor detected
Light blue Video signal supported; monitor detected
Pos: 23 /806-IHSE/Ins tallation/UEB_I nstallation @ 5\mod_127857497 1589_6.doc @ 41768 @ 1 @ 1
