Ihse Draco compact DVI 477 Series User Manual

Troubleshooting
2021-07-09 67
8.1 USB 2.0
CPU Unit
CON Unit
Rear View
Rear View
Diagnosis
Possible Reason
Measure
CPU Unit:
All LEDs off
No connection to CPU  Check connection USB cable to
CPU; select another USB port if
necessary.
 Remove USB and power cable
and restart CPU. Connect power
cable first.
CON Unit:
LED 3 red
Connection between
CON Unit and CPU Unit
 Check interconnect cable and
connectors.
CON Unit:
LED 3 flashing
green / light
blue and
USB 2.0 device
without function
No USB 2.0 device  Connect USB 2.0 device.
USB 2.0 device is not
supported
 Check installation at the CPU,
also the necessary drivers.
 New connection of the USB 2.0
device.
 Contact dealer if necessary.
