7.2.2 Fiber
A point
-to-point connection is necessary. Operation with multiple patch
panels is allowed. Routin
g over active network components, such as
Ethernet Hubs, Switches or Routers, is not allowed.
Type of Interconnect Cable
(Cable notations according to VDE)
Type of cable
Specifications
Single-mode 9μm  Two fibers 9μm
 I-V(ZN)H 2E9 (in-house patch cable)
 I-V(ZN)HH 2E9 (in-house breakout cable)
 I/AD(ZN)H 4E9 (in-house or outdoor
breakout cable, resistant)
 A/DQ(ZN)B2Y 4G9 (outdoor cable, with
protection against rodents)
Multi-mode 50μm  Two fibers 50μm
 I-V(ZN)H 2G50 (in-house patch cable)
 I/AD(ZN)H 4G50 (in-house or outdoor
breakout cable, resistant)
Maximum Transmission Range (End-to-End Connection)
Type of cable Bandwidth
Maximum transmission
range
Video / USB-
HID signal
USB 2.0
signal*
Single-mode 9μm 1G 10.000 m
(32.800 ft)
2.000 m
(6.560 ft)
Single-mode 9μm 3G 5.000 m
(16.400 ft)
2.000 m
(6.560 ft)
Multi-mode 50μm (OM3) 1G/3G 1.000 m
(3.280 ft)
1.000 m
(3.280 ft)
Multi-mode 50μm 1G/3G 400 m
(1.300 ft)
400 m
(1.300 ft)
* The transmission range for the transparent USB signal applies to the
following products:
477-1SESA / -1SEXA / -1SESD /-1SEXD / 1SUS/-1SUX
W
hen using single-mode SFPs with multi-mode fiber optic cables, the
maximum
transmission range can usually be doubled.
