Ihse Draco compact DVI 477 Series User Manual

Specifications
2021-07-09 51
7.2 Interconnect Cable
Pos: 49 /806-IHSE/T echnische Daten/Verbi ndungskabel/V erbindungskabel (Cat X) @ 5\mod_1278578406026_6. doc @ 42205 @ 3 @ 1
7.2.1 Cat X
A point
-to-
point connection is required. Operation with several patch fields
is possible. Routing ov
er an active network component, such as an
Ethernet Hub, Router or Matrix, is not allowed.

Avoid routing Cat X cables along power cables.
To maintain regulatory EMC compliance, correctly installed shielded Cat
X
cable must be used throughout the inter
connection link.
To maintain reg
ulatory EMC compliance, all Cat X cables need to carry
fe
rrites on both cable ends close to the device.
Type of Interconnect Cable
The KVM Extender requires interconnect cabling specified for Gigabit
Ethernet (1000BASE-T). The use of solid-core (AWG24), shielded, Cat 5e
(or better) is recommended.
Type of cable
Specifications
Cat X Solid-Core Cable
AWG24
S/UTP (Cat 5e) cable according to EIA/TIA-
568-B. Four pairs of wires AWG24.
Connection according to EIA/TIA-568-B
(1000BASE-T).
Cat X Patch Cable
AWG26/8
S/UTP (Cat 5e) cable according to EIA/TIA-
568-B. Four pairs of wires AWG26/8.
Connection according to EIA/TIA-568-B
(1000BASE-T).
The use of flexible cables (patch cables) type
AWG26/8 is possible,
however the maximum possible extension dist
ance is halved.
Pos: 85 /806-IHSE/Technisc he Daten/Verbindung skabel/Verbi ndungskabel (Cat X)_Kabel länge 477-xx @ 5\mod_1278937761105_ 6.doc @ 43167 @ @ 1
Maximum Transmission Range (End-to-End Connection
Type of cable Maximum transmission range
Cat X Installation Cable
AWG24
140 m (400 ft)
Cat X Patch Cable
AWG26/8
70 m (200 ft)
Pos: 51 /806-IHSE/T echnische Daten/Verbi ndungskabel/V erbindungskabel (LWL) @ 5\mod_1278937967667_6.doc @ 43186 @ 3 @ 1
