Draco compact DVI KVM Extender
36 2021-07-09
5 Configuration
Pos: 29 /806-IHSE/ Konfiguration/Über tragungsparamet er/477-xx @ 5 \mod_1278937002401_6.doc @ 43075 @ 2 @ 1
5.1 Transmission Parameters
The device operates with a proprietary compression method.
In default configuration, the device adapts dynamically to monitor
resolution and image content. This configuration is suitable for almost all
conditions and should only be modified if image quality is not fully
satisfactory.
In exceptional cases the displayed video image may exhib
it "frame
dropping" (loss of single
pictures) or color effects.
Pos: 30 /806-IHSE/ Konfiguration/DDC -Einstellungen/ 477-xx @ 5\mod_1278937107 542_6.doc @ 43093 @ 2 @ 1
5.2 DDC Settings
By default, the device transmits the factory preset DDC information to the
CPU. This information is suitable in most cases.
Downloading of the DDC information of the console monitor can be
performed during normal operation (see Chapter 6.1, Page 43).
For special requirements, DDC information can be retrieved and uploaded
as a binary file to both the CPU Unit and the CON Unit.
Connect your computer with a USB mini cable to the service port of the
CPU Unit or CON Unit.
The data area of the unit is now accessible as a flash drive "Extender".
Uploading DDC Information
Copy the binary file containing your specific DDC information to the flash
drive of the CPU Unit or CON Unit.
The current DDC information is replaced.
Retrieving DDC Information
Copy the file "DDC-EDID.bin" on the flash drive of the CPU Unit to your
computer.
To open the binary file, you have to install a suitable software, e.g.
WinDDCwrite, on your computer. Contact your dealer for this purpose.
Reset to Factory DDC Information
Delete the file called "DDC-EDID.bin" on the flash drive of the CPU Unit.
By deleting this file, the factory DDC Information is restored.
