3.6 Device Views
Pos: 10 /806-IHSE/ Beschreibung/Ger äteansichten/477-xx /1SHC (Singl e-Head Cat X) @ 5\mod_1278934284 276_6.doc @ 42920 @ 3 @ 1
3.6.1 Model K477-1SHC (Single-Head Cat X)
CPU
Unit CON Unit
Rear View
Rear View
1 Connect to 5VDC power
supply
2
Service port
3
Connect to interconnect cable
4
To CPU: USB-HID
5
To CPU: DVI-D
1 Connect to 5VDC power
supply
2 Service port
3 Connect to interconnect cable
4 Connect to USB-HID devices
5 Connect to DVI monitor
Pos: 11 /806-IHSE/ Beschreibung/Gerät eansichten/477-xx /1SHS _1SHX (Single-Head Glas faser) @ 5\mod_1278934861511_ 6.doc @ 42940 @ 3 @ 1
3.6.2 Model K477-1SHS / -1SHX (Single-Head Fiber)
CPU Unit
CON Unit
Rear View
Rear View
1 Connect to 5VDC power
supply
2
Service port
3
Connect to interconnect cable
4
To CPU: USB-HID
5
To CPU: DVI-D
1 Connect to 5VDC power
supply
2 Service port
3 Connect to interconnect cable
4 Connect to USB-HID devices
5 Connect to DVI monitor
