Ihse Draco compact DVI 477 Series - USB 2.0 Add-On

Draco compact DVI KVM Extender
66 2021-07-09
8.7 USB 2.0 Add-On
CPU Unit
CON Unit
Rear View
Rear View
Diagnosis Possible Reason Measure
CPU & CON
Unit:
LED 3 off
No connection to CPU  Check connection USB cable to
CPU; select another USB port if
necessary.
 Remove USB and power cable
and restart CPU. Connect power
cable first.
CPU & CON
Unit:
LED 2 off
No connection between
CON Unit and CPU Unit
 Check interconnect cable and
connectors.
CPU & CON
Unit:
LED 2 off and
USB 2.0 device
without function
No USB 2.0 device  Connect USB 2.0 device.
USB 2.0 device is not
supported
 Check installation at the CPU,
also the necessary drivers.
 New connection of the USB 2.0
device.
 Contact dealer if necessary.
