Ihse Draco compact DVI 477 Series User Manual

Draco compact DVI KVM Extender
20 2021-07-09
3.6.9 Model K477-1SHCV (Single-Head Cat X with VGA)
CPU Unit
CON Unit
Rear View
Rear View
1 Connect to 5VDC power
supply
2
Service port (KVM)
3
Connect to interconnect cable
4
To CPU: USB-HID
5
To CPU: DVI-I (VGA / DVI)
6
Service port (DVI-I)
7
IR receiver for remote control
1 Connect to 5VDC power
supply
2 Service port
3 Connect to interconnect cable
4 Connect to USB-HID devices
5 Connect to DVI monitor
CPU Unit
CON Unit
Front View
Front View
1 IR receiver for remote control
1 IR receiver for remote control
Pos: 19 /806-IHSE/ Beschreibung/Ger äteansichten/477-xx _COMP/1SHSV / -1SHXV (Glasfaser mit VGA) @ 5\mod_12916479103 18_6.doc @ 45910 @ 3 @ 1
