Ihse Draco compact DVI 477 Series User Manual

Draco compact DVI KVM Extender
46 2021-07-09
Other USB-HID devices
The proprietary USB emulation also supports certain other USB-HID
devices, such as specific touch screens, graphic tablets, barcode
scanners or special keyboards. Support cannot be guaranteed, however,
for every USB-HID device.
Only two USB
-HID devices are supported concurrently, such as keyboard
and mouse or keyboard and touch screen. A hub is allowed, but it does
not increase the number of HID devices allowed.
To sup
port other USB 'non-HID' devices, such as scanners, web cams or
memory devices, choos
e our devices with transparent USB support.
Pos: 42 /806-IHSE/T echnische Daten/Sc hnittstellen/USB 2. 0 (transparent) @ 5\mod_12785783 16386_6.doc @ 42168 @ 3 @ 1
7.1.4 USB 2.0 (transparent)
KVM Extender models with transparent USB 2.0 support allow the
connection of all types of USB 2.0 devices (without restriction). USB 2.0
data transfer is supported, depending on the upgrade module, with USB
high speed (max. 480 Mbit/s) or USB full speed (max. 36 Mbit/s).
Each USB full speed port provides a maximum current of 500 mA (high
power). When using a USB high speed interface with 4 USB ports,
respectively 2 connectors provides a maximum of 500 mA (high power)
and 2 connectors a maximum of 100 mA.
Pos: 43 /806-IHSE/T echnische Daten/ Schnittst ellen/RJ45 (Ger ätekommunikati on) @ 5\mod_1278578339308_6. doc @ 42186 @ 3 @ 1
7.1.5 RJ45 (Interconnect)
Communication between Cat X devices requires a 1000BASE-T
connection.
Connector wiring must comply with EIA/TIA-568-B (1000BASE-T), with
RJ45 connectors at both ends. All four cable wire pairs are used.
Pos: 44 /806-IHSE/T echnische Daten/Sc hnittstellen/Glasf aser SFP Typ LC @ 5\mod_1278937700855 _6.doc @ 43149 @ 3 @ 1
7.1.6 Fiber SFP Type LC (Interconnect)
Communication of fiber devices is performed via Gigabit SFPs that are
connected to suitable fibers fitted with connectors type LC ().
The correct function of the device can only be guaranteed with SFPs
p
rovided by the manufacturer.
SF
P modules can be damaged by electrostatic discharge (ESD).

Please consider ESD handling specifications.
Pos: 45 /806-IHSE/T echnische Daten/Sc hnittstellen/Seri elle Schnittstell e @ 5\mod_1291127444390_6.doc @ 44828 @ 3 @ 1
