Platinum™ VX
Installation and Operation Manual Parameters
© 2016 Imagine Communications Corp. Proprietary and Confidential. Version 1.2 | Page 111
SFP+HDMI+OUT Electrical Transmitter Parameters
Table 40: SFP+HDMI+Out Output Parameters
Name
Description
Type
Options
Output SFP ID
Reports the type of SFP
RO
SFP+HDMI+OUT
Output Port Type
SFP Description
RO
HDMI TX
Output SFP Temperature
Displays the internal temperature
for the SFP
RO
Range:-198 to 262 °F
(-128 to 128 °C)
Output Reclocker Mode
Sets the reclock mode to automatic
or bypass or to one of three
manual fixed rates
RW
 Auto
 SD
 HD
 3G
 Bypass
Output Data Rate
Reports the signal rate detected
RO
 Unknown
 SD
 HD
 3G
 No Signal
Switch Point
RW
 Switch Point 1
 Switch Point 2
 Switch Point 3
 Switch Point 4
EDH Presence
Reports the presence of EDH
packages for SD-SDI
RO
 Yes
 No
Emb Audio Group Presence
Reports the presence of an
embedded audio group
RO
 <String>
HDMI Output Module
Sets the output mode
(This control must be set to the
correct value to enable the SFP
module.)
RW
 HDMI
 DVI
HDMI Output Format
Sets the output video format
RW
 RGB 444
 YCbCr 422
 YCbCr 444
Clock Termination
Detects the presence of a
termination (sink) device
RO
 Yes
 No
